BCF type explosion-proof dehumidifier (ⅡB,ⅡC)

Location:

Product Center

Product Center

Explosion-proof Electrical Appliances

Explosion-proof lamp

Explosion-proof Tube Articles

Explosion-proof electric appliances

Dust Appliances

Waterproof and dustproof protection class

BCF type explosion-proof dehumidifier (ⅡB,ⅡC)

Product Details
Return

型号含义 Model implication

适用范围 Applications

1.1区、2区或20区、21区、22区危险场所；
2.ⅡA、ⅡB类爆炸性气体环境；
3.本产品适用于石油化工、冶金、医药、轻工、纺织、食品、生物工程、航天航
空工程以及军工等爆炸性环境中，有温度控制要求的场所；
4.环境温度：-15℃~+40℃；
5.温度组别：T1~T4；
6.应用于石油、化工、航天、军工等场所。
1.Hazardous:division 1&2 or zone 20、21、22;
2.Explosive gas atmosphere:class ⅡA、ⅡB;
3.It's used in petroleum, metallurgy, medicine, light industry, textile, foodstuffand biology, aviation project and military industries, in exp-losive environmentwith temperature with temperature control requirements;
4.Temperature: -15~+40℃;
5.Temperature class:T1~T4;
6.Widely using in the fields of oil, chemical industry, spaceflight, war ind-ustruand so on.

产品特点 Features

1.防爆除湿机主要在普通除湿面的基础上，对操作、调节部分以及内部的电器控制部分、压缩机和电机等适用特殊工艺处理和制造方法进行主爆处理，其外形尺寸及安装方式同普通除湿机；
2.出厂产品均附有整套技术资料，便于安装，使用和维护；
3.可对用户现场的大型除湿机进行现场防爆处理，并可申请防爆检测中心进行整机防爆性能检测。
1.Exposion-proof dehumidifier is made of common dehumidifier, but do exposion-proof treatment for the operation, regulationparts, intertal control pare, compressor and motor by special method. Its outline size and installation way are as same as the common dehumidifier;
2.The whole set of technical documentation is attached with this product when it is packed for your convenience of forinstallation. Operation and maintenance;
3.We can do explosion-proof treatment for large dehumidifier on locale, and apply for explosion-proof function inspectionfrom explosion-proof inspection centre.

主要技术参数 Main technical parameters

产品型号 Type	BCF-0.2Y	BCF-0.4Y	BCF-3Y	BCF-3.2Y	BCF-6	BCF-6.3
性能参数 Perfrmance	BCF-0.2Y	BCF-0.4Y	BCF-3Y	BCF-3.2Y	BCF-6	BCF-6.3
相对湿度(RH) Relative humidity	60%	60%	70%	60%	70%	60%
工作电压 Rated volage(V)	AC220	AC220	AC220	AC220	3N~380V	3N~380V
电源频率(Hz) Power freauency	50	50	50	50	50	50
除湿量(Kg/h) Dehumidity capacity	0.2	0.4	3	3.2	6	6.3
额定输入功率(W) Rated input power	175	300	1200	1850	2900	3800
额定电流 Rated current(A)	0.9	1.4	6	8.6	5.4	7
外形尺寸Dimension(mm) 长×宽×高L×W×H	310×210×520	320×375×685	500×365×1000	540×440×1050	600×400×1820	600×435×1950
适用面积(m2)高度2.3米内 Area(Height is within 2.3 m)	6~8	10~14	50~70	55~75	100~120	110~125
防爆标志 Ex-mark	ExdmⅡBT4等效于 Ⅱ2G ExdmⅡBT4(欧标) ExdmⅡCT4等效于 Ⅱ2G ExdmⅡCT4(欧标)
注：以上参数(除湿量测试标况为27℃)仅供参考，具体数据详见《产品使用说明书》。 Note:The parameter (at 27℃)is only for reference.please observe our product instruction or contact us for more information
